Dell PowerConnect 5324 Command Line Interface Reference Manual

248 SNMP Commands
www.dell.com | support.dell.com
Command Mode
Global Configuration mode
User Guidelines
• Although the CLI can set any required configuration, there might be a situation where a
SNMP user sets a MIB variable that does not have an equivalent command. In order to
generate configuration files that support those situations, the
snmp-server set command is
used.
•
This command is context sensitive.
Examples
The following example sets the scalar MIB "sysName" to have the value "dell".
The following example sets the entry MIB "rndCommunityTable" with keys 0.0.0.0 and "public".
The field rndCommunityAccess gets the value "super" and the rest of the fields get their default
values.
snmp-server group
To configure a new Simple Network Management Protocol (SNMP) group, or a table that maps
SNMP users to SNMP views, use the snmp-server group global configuration command. To remove
a specified SNMP group, use the no form of this command.
Syntax
snmp-server group groupname { v1 | v2 | v3 { noauth | auth | priv } [ notify notifyview ] } [ context
name]
[ read readview] [ write writeview]
no snmp-server group groupname [ v1 | v2 | v3 [ noauth | auth | priv ]] [ context name]
•
groupname — The name of the group. (Range: Up to 30 characters)
•
v1 — SNMP Version 1 security model.
•
v2 — SNMP Version 2 security model.
•
v3 — SNMP Version 3 security model.
•
noauth — Specifies no authentication of a packet. Applicable only to SNMP Version 3
security model.
•
auth — Specifies authentication of a packet without encrypting it. Applicable only to
SNMP
Version 3 security model.
Console (config)# snmp-server set sysName sysname dell
Console (config)# snmp-server set rndCommunityTable
rndCommunityMngStationAddr 0.0.0.0 rndCommunityString public
rndCommunityAccess super

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
