Dell PowerConnect 5324 Command Line Interface Reference Manual

SNMP Commands 255
.
show snmp views
To display the configuration of views use the show snmp views Privileged EXEC command
Syntax
show snmp views [ viewname ]
•
viewname — The name of the view. Range: Up to 30 characters
Default Configuration
There is no default configuration for this command.
Command Modes
Privileged EXEC
User Guidelines
• There are no user guidelines for this command
Example
The following example displays the configuration of views use the show snmp views Privileged
EXEC command.
Traps are enabled.
Authentication trap is enabled.
Version 1,2 notifications
Target
Address
Type Communit
y
Version UDP Port Filter
name
TO sec
Retrie
s
Version 3 notifications
Target
Address
Type Username Secu-
rity
Level
UDP Port Filter
name
TO sec Retrie
s
System Contact:
System Location:
console#

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
