Dell PowerConnect 5324 Command Line Interface Reference Manual

Address Table Commands 87
show bridge address-table static
The show bridge address-table static Privileged EXEC mode command displays statically created
entries in the bridge-forwarding database.
Syntax
show bridge address-table static [ vlan vlan ] [ ethernet interface | port-channel port-channel-
number
]
•
vlan —Specific valid VLAN, such as VLAN 1.
•
interface— A valid Ethernet port .
• port-channel-number —A valid port-channel number.
Default Configuration
This command has no default configuration.
Command Mode
Privileged EXEC mode
User Guidelines
• There are no user guidelines for this command.
Example
In this example, all static entries in the bridge-forwarding database are displayed.
Console# show bridge address-table
Aging time is 300 sec
vlan mac address port type
---- ----------- ---- ----
1 00:60:70:4C:73:FF g8 dynamic
1 00:60:70:8C:73:FF g7 dynamic
200 00:10:0D:48:37:FF g4 static
8 00:10:0D:48:37:FF g2 dynamic

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
