Dell PowerConnect 5324 Command Line Interface Reference Manual

350 VLAN Commands
www.dell.com | support.dell.com
Command Mode
Interface configuration (Ethernet, port-channel)
User Guidelines
• An internal usage VLAN is required when an IP interface is defined on Ethernet port or Port-
channel.
• Using this command the user can define the internal usage VLAN of a port.
• If an internal-usage is not defined for a Port, and the user wants to define an IP interface, the
software chooses one of the unused VLANs.
• If a VLAN ID was chosen by the software for internal usage, and the user wants to use that
VLAN ID for static or dynamic VLAN, he should either remove the IP interface, creates the
VLAN, and recreate the IP interface, or use this command to define explicit internal usage
VLAN.
Examples
The following example reserves a VLAN as the internal usage VLAN of an interface.
show vlan
The show vlan Privileged EXEC mode command displays VLAN information.
Syntax
show vlan [ tag vlan-id | name vlan-name ]
•
vlan-id —A valid VLAN ID
•
vlan-name —A valid VLAN name string. (Range: 1 - 32 characters)
Default Configuration
This command has no default configuration.
Command Mode
Privileged EXEC mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example displays all VLAN information.
Console (config)# ip internal-usage-vlan 10

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
