Dell PowerConnect 5324 Command Line Interface Reference Manual

SNMP Commands 257
show snmp filters
To display the configuration of filters use the show snmp filters Privileged EXEC command .
Syntax
show snmp filters [ filtername ]
• filternam — The name of the view . Range: Up to 30 character
Default Configuration
There is no default configuration for this command.
Console # show snmp
groups
Name Security Views
Model Level Context Read Write Notify
user-group V3 priv - Default -
managers-group V3 priv - Default Default -
managers-group V3 priv - Default -
Console # show snmp groups user-group
Name: user-group
Security Model: V3
Security Level: priv
Security Context: -
Read View: Default
Write View: ""
Notify View: ""

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
