Dell PowerConnect 5324 Command Line Interface Reference Manual

122 Ethernet Configuration Commands
www.dell.com | support.dell.com
• 1000 —Force 1000 Mbps operation.
•
10000 —Force 10000 Mbps operation.
Default Configuration
Maximum port capability.
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• The command " no speed " in port-channel context returns each port in the port-channel to its
maximum capability.
Example
The following example configures the speed operation of Ethernet g5 to force 100-Mbps operation.
duplex
The duplex Interface Configuration mode command configures the full/half duplex operation of a
given Ethernet interface when not using auto-negotiation. To restore the default, use the
no form
of this command.
Syntax
duplex { half | full }
no duplex
• half —Force half-duplex operation
•
full —Force full-duplex operation
Default Configuration
The interface is set to full duplex.
Command Mode
Interface Configuration (Ethernet) mode
User Guidelines
• Before attempting to force a particular duplex mode on the port operating at 10/100/1000
Mbps, disable the auto-negotiation on that port.
Console(config)# interface ethernet g5
Console(config-if)# speed 100

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
