Dell PowerConnect 5324 Command Line Interface Reference Manual

126 Ethernet Configuration Commands
www.dell.com | support.dell.com
Example
In the following example Back Pressure is enabled on g5.
port jumbo-frame
The port jumbo-frame Global Configuration mode command enables jumbo frames for the device.
The size of the port jumbo frame is 10K. To disable jumbo frames, use the
no form of this
command.
Syntax
port jumbo-frame
no port jumbo-frame
Default Configuration
Jumbo Frames are not enabled.
Command Mode
Global Configuration mode
User Guidelines
• The command would be effective only after reset.
Example
In the following example, Jumbo Frames are enabled on the device.
clear counters
The clear counters User EXEC mode command clears statistics on an interface.
Syntax
clear counters [ ethernet interface | port-channel port-channel-number ]
•
interface— Valid Ethernet port.
• port-channel-number— Valid port-channel trunk index.
Default Configuration
This command has no default configuration.
Console(config)# interface ethernet g5
Console(config-if)# back-pressure
Console(config)# port jumbo-frame

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
