rmon table-size
The rmon table-size Global Configuration mode command configures the maximum RMON
tables sizes. To return to the default configuration, use the
no form of this command.
Syntax
rmon table-size { history entries | log entries }
no rmon table-size { history | log }
•
history entries —Maximum number of history table entries. (Range: 20 - 32767)
•
log entries —Maximum number of log table entries. (Range: 20 - 32767)
Default Configuration
History table size is 270.
Log table size is 200.
Command Mode
Global Configuration mode
User Guidelines
• The configured table size is effective after the device is rebooted.
Example
The following example configures the maximum RMON history table sizes to 1000 entries.
Console (config)# rmon table-size history 1000

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
