Dell PowerConnect 5324 Command Line Interface Reference Manual

182 LLDP Commands
www.dell.com | support.dell.com
Syntax
lldp reinit-delay seconds
no
lldp reinit-delay
• seconds — Specifies the minimum time in seconds an LLDP port will wait before
reinitializing LLDP transmission. (Range 1-10 seconds).
Default Configuraiton
2 seconds
Command Modes
Global configuration
User Guidelines
There are no user guidelines for this command.
Examples
The following example specifies the minimum time an LLDP port will wait before reinitializing
LLDP transmission.
lldp tx-delay
To specify the delay between successive LLDP frame transmissions initiated by value/status
changes in the LLDP local systems MIB, use the
lldp tx-delay command in global configuration
mode. To revert to the default setting, use the
no form of this command.
Syntax
lldp tx-delay seconds
no
lldp tx-delay
Parameters
• seconds — Specifies the delay in seconds between successive LLDP frame transmissions
initiated by value/status changes in the LLDP local systems MIB. Range 1-8192 second.
Default Configuration
The default value is 2 seconds
Command Modes
Global configuration
Console (config) # lldp reinit-delay 6

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
