Dell PowerConnect 5324 Command Line Interface Reference Manual

Ethernet Configuration Commands 119
Ethernet Configuration Commands
interface ethernet
The interface ethernet Global Configuration mode command enters the interface configuration
mode to configure an Ethernet type interface.
Syntax
interface ethernet interface
• interface— Valid Ethernet port.
Default Configuration
This command has no default configuration.
Command Mode
Global Configuration mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example enables ports g8 for configuration.
interface range ethernet
The interface range ethernet Global Configuration mode command enters the interface
configuration mode to configure multiple Ethernet type interfaces.
Syntax
interface range ethernet { port-range | all }
•
port-range— List of valid ports to add. Separate non consecutive ports with a comma and
no spaces; a hyphen is used to designate a range of ports.
•
all —All Ethernet ports.
Default Configuration
This command has no default configuration.
Console(config)# interface ethernet g8
Console(config-if)#

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
