Dell PowerConnect 5324 Command Line Interface Reference Manual

VLAN Commands 343
Default Configuration
VID=1
Command Mode
Interface configuration (Ethernet, port-channel) mode
User Guidelines
• The command automatically removes the port from the previous VLAN, and adds it to the
new VLAN.
Example
The following example configures a VLAN ID of 23 to the untagged layer 2 VLAN interface
number g8.
switchport trunk allowed vlan
The switchport trunk allowed vlan Interface Configuration mode command adds or removes
VLANs, to or from a trunk port.
Syntax
switchport trunk allowed vlan { add vlan-list | remove vlan-list }
•
add vlan-list —List of VLAN IDs to add. Separate non consecutive VLAN IDs with a
comma and no spaces. A hyphen designates a range of IDs.
•
remove vlan-list —List of VLAN IDs to remove. Separate non consecutive VLAN IDs with
a comma and no spaces. A hyphen designate a range of IDs.
Default Configuration
This command has no default configuration.
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• There are no user guidelines for this command.
Console (config)# interface ethernet g8
Console (config-if)# switchport access vlan
23

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
