Dell PowerConnect 5324 Command Line Interface Reference Manual

Spanning-Tree Commands 261
Spanning-Tree Commands
spanning-tree
The spanning-tree Global Configuration mode command enables spanning-tree functionality. To
disable spanning-tree functionality, use the
no form of this command.
Syntax
spanning-tree
no spanning-tree
Default Configuration
Spanning-tree is enabled.
Command Modes
Global Configuration mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example enables spanning-tree functionality.
spanning-tree mode
The spanning-tree mode Global Configuration mode command configures the spanning-tree
protocol. To return to the default configuration, use the
no form of this command.
Syntax
spanning-tree mode { stp | rstp | mstp }
no spanning-tree mode
• stp —STP is the Spanning Tree operative mode.
•
rstp —RSTP is the Spanning Tree operative mode.
•mstp —MSTP is enabled
Default Configuration
STP
Console(config)# spanning-tree

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
