Dell PowerConnect 5324 Command Line Interface Reference Manual

SSH Commands 297
• dsa —DSA key.
Default Configuration
By default, there are no keys.
Command Mode
SSH Public Key Chain Configuration mode
User Guidelines
• Follow this command with the key-string command to specify the key.
Example
The following example enables a SSH public key to be manually configured for the SSH public key
chain called "bob".
key-string
The key-string SSH Public Key-String Configuration mode command manually specifies a SSH
public key.
Syntax
key-string row key-string
• row— Specify SSH public key row by row
•
key-string— UU-encoded DER format is the same format in authorized_keys file used by
OpenSSH.
Default Configuration
By default, the keys do not exist.
Command Mode
SSH Public Key-string configuration
User Guidelines
• Use the key-string row command to specify the SSH public key row by row. Each row must
begin with the
key-string row command. This command is useful for configuration files.
• UU-encoded DER format is the same format in authorized_keys file used by OpenSSH.
Console(config-pubkey-chain)# user-key bob rsa
Console(config-pubkey-key)# key-string row key-string
AAAAB3NzaC1yc2EAAAADAQABAAABAQCvTnRwPWl

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
