Dell PowerConnect 5324 Command Line Interface Reference Manual

342 VLAN Commands
www.dell.com | support.dell.com
Example
The following example groups VLAN 221 until 228 and VLAN 889 to receive the same command.
name
The name Interface Configuration mode command adds a name to a VLAN. To remove the VLAN
name use the
no form of this command.
Syntax
name string
no name
• string —Unique name, up to 32 characters in length, to be associated with this VLAN.
Default Configuration
No name is defined.
Command Mode
Interface Configuration (VLAN) mode
User Guidelines
• The VLAN name should be unique.
Example
The following example names VLAN number 19 with the name "Marketing".
switchport access vlan
The switchport access vlan Interface Configuration mode command configures the VLAN ID
when the interface is in access mode. To reconfigure the default, use the
no form of this command.
Syntax
switchport access vlan vlan-id
no switchport access vlan
• vlan-id —VID of the VLAN to which the port is configured.
Console (config)# interface range vlan 221-228,889
Console (config-if)#
Console (config)# interface vlan 19
Console (config-if)# name Marketing

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
