Dell PowerConnect 5324 Command Line Interface Reference Manual

358 Web Server
www.dell.com | support.dell.com
User Guidelines
• There are no user guidelines for this command. However, specifying 0 as the port number will
effectively disable HTTP access to the device.
Example
The following example shows how the http port number is configured to 100.
ip https server
The ip https server Global Configuration mode command enables the device to be configured
from a secured browser. To disable this function, use the
no form of this command.
Syntax
ip https server
no ip https server
Default Configuration
The default for the device is disabled.
Command Mode
Global Configuration mode
User Guidelines
• You must use the crypto certificate generate command to generate the HTTPS certificate.
Example
The following example enables the device to be configured from a browser.
ip https port
The ip https port Global Configuration mode command configures a TCP port for use by a secure
web browser to configure the device. To use the default port, use the
no form of this command.
Syntax
ip https port port-number
no ip https port
• port-number —Port number for use by the HTTP server. (Range: 0 - 65535)
Console (config)# ip http port 100
Console (enable)# ip https server

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
