290 Spanning-Tree Commands
www.dell.com | support.dell.com
spanning-tree mst mstp-rstp
Use the
spanning-tree mst mstp-rstp
global configuration command to configure the switch to
convert STP/RSTP packets to MSTP instances. Use the
no
form of this command to disable the
configuration.
Syntax
spanning-tree mst
mstp-rstp
no
spanning-tree mst
mstp-rstp
This command has no arguments or keywords.
Address 00:02:4b:19:7a:00
Path Cost 10000
Rem hops 19
Bridge ID Priority 32768
Address 00:02:4b:29:7a:00
Hello Time 2 sec Max Age 20 sec Forward
Delay 15 sec Max hops 20
Console# show spanning-tree
Spanning tree enabled mode MSTP
Default port cost method: long
###### MST 0 Vlans Mapped: 1-9
CST Root ID Priority 32768
Address 00:01:42:97:e0:00
This switch is root for
CST and IST master
Hello Time 2 sec Max Age 20 sec Forward
Delay 15 sec Max hops 20
