Dell PowerConnect 5324 Command Line Interface Reference Manual

Command Groups 33
Radius Commands
qos trust (Global) Configures the system to basic mode and the "trust"
state.
Global
Configuration
qos trust (Interface)
Enables each port trust state Interface
Configuration
qos cos Configures the default port CoS value. Interface
Configuration
show qos map Displays all the maps for QoS. User EXEC
Command Group Description Access Mode
radius-server host Specifies a RADIUS server host. Global
Configuration
radius-server key Sets the authentication and encryption key for all
RADIUS communications between the router and the
RADIUS daemon.
Global
Configuration
radius-server
retransmit
Specifies the number of times the software searches the
list of RADIUS server hosts.
Global
Configuration
radius-server source-ip Specifies the source IP address used for communication
with RADIUS servers.
Global
Configuration
radius-server timeout Sets the interval for which a router waits for a server host
to reply.
Global
Configuration
radius-server deadtime Improves RADIUS response times when servers are
unavailable.
Global
Configuration
show radius-servers Displays the RADIUS server settings. Privileged User
EXEC

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
