Dell PowerConnect 5324 Command Line Interface Reference Manual

266 Spanning-Tree Commands
www.dell.com | support.dell.com
Command Modes
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• When STP is disabled, the device will not forward STP BPDU's based on the Forward BPDU's
setting.
Example
The following example disables spanning-tree on g5.
spanning-tree cost
The spanning-tree cost Interface Configuration mode command configures the spanning-tree path
cost for a port. To reset the default port path cost, use the
no form of this command.
Syntax
spanning-tree cost cost
no spanning-tree cost
• cost —The port path cost (Range: 1 - 200,000,000)
Default Configuration
For the default short pathcost method, the cost values are: port channel - 4; 1000 mbps - 4;
100 mbps - 19; 10 mbps - 100.
Command Modes
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• The method used (long or short) is set by using the spanning-tree pathcost method
command.
Example
The following example configures the spanning-tree cost on g5 to 35000.
Console (config)# interface ethernet g5
Console (config-if)# spanning-tree disable
Console(config)# interface ethernet g5
Console(config-if)# spanning-tree cost 35000

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
