Dell PowerConnect 5324 Command Line Interface Reference Manual

Spanning-Tree Commands 267
spanning-tree port-priority
The spanning-tree port-priority Interface Configuration mode command configures port priority.
To reset the default port priority, use the
no form of this command.
Syntax
spanning-tree port-priority priority
no spanning-tree port-priority
• priority —The port priority. (Range: 0 - 240 in multiples of 16)
Default Configuration
The default port-priority for IEEE STP is 128.
Command Modes
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example configures the spanning priority on g5 to 96.
spanning-tree portfast
The spanning-tree portfast Interface Configuration mode command enables PortFast mode. In
PortFast mode, the interface is immediately put into the forwarding state upon linkup, without
waiting for the timer to expire. To disable PortFast mode, use the
no form of this command.
Syntax
spanning-tree portfast
no spanning-tree portfast
Default Configuration
PortFast mode is disabled.
Command Modes
Interface Configuration (Ethernet, port-channel) mode
Console(config)# interface ethernet g5
Console(config-if)# spanning-tree port-priority 96

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
