Dell PowerConnect 5324 Command Line Interface Reference Manual

IGMP Snooping Commands 151
Syntax
ip igmp snooping host-time-out time-out
no ip igmp snooping host-time-out
• time-out —Host timeout in seconds. (Range: 1 - 2147483647)
Default Configuration
The default host-time-out is 260 seconds.
Command Mode
Interface Configuration (VLAN) mode
User Guidelines
• The timeout should be at least greater than 2*query_interval+max_response_time of the
IGMP router.
Example
The following example configures the host timeout to 300 seconds.
ip igmp snooping mrouter-time-out
The ip igmp snooping mrouter-time-out Interface Configuration mode command configures the
mrouter-time-out. The
mrouter-time-out command is used for setting the aging-out time after
multicast router ports are automatically learned. To configure the default mrouter-time-out, use
the
no form of this command.
Syntax
ip igmp snooping mrouter-time-out time-out
no ip igmp snooping mrouter-time-out
• time-out —mrouter timeout in seconds (Range: 1 - 2147483647)
Default Configuration
The default value is 300 seconds.
Command Mode
Interface Configuration (VLAN) mode
Console (config)# interface vlan 2
Console (config-if)# ip igmp snooping host-time-out 300

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
