Dell PowerConnect 5324 Command Line Interface Reference Manual

LLDP Commands 183
Usage Guidelines
• It is recommended that the TxDelay would be less than 0.25 of the LLDP timer interval.
Examples
The following example specifies the delay between successive LLDP frame transmissions initiated
by value/status changes in the LLDP local systems MIB.
lldp optional-tlv
To specify which optional TLVs from the basic set should be transmitted, use the lldp optional-tlv
command in interface configuration mode. To revert to the default setting, use the
no form of this
command.
Syntax
lldp optional-tlv tlv1 [tlv2 … tlv5]
no
lldp optional-tlv
• tlv — Specifies TLV that should be included. Available optional TLVs are: port-desc, sys-
name, sys-desc and sys-cap . (Range 1-8192 seconds).
Default Configuration
No optional TLV is transmitted.
Command Modes
Interface configuration (Ethernet)
User Guidelines
• There are no user guidelines for this command.
Example
The following example specifies which optional TLV (2)s from the basic set should be transmitted.
lldp management-address
To specify the management address that would be advertised from an interface, use the lldp
management-address
command in interface configuration mode. To stop advertising management
address information, use the
no form of this command.
Console (config) # lldp tx-delay 7
Console(config)# interface ethernet g5
Console(config-if)# lldp optional-tlv sys-name

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
