Dell PowerConnect 5324 Command Line Interface Reference Manual

AAA Commands 73
Default Configuration
No password is required.
Command Mode
Line Configuration mode
User Guidelines
• There are no user guidelines for this command.
Example
The following example specifies a password "secret" on a line.
enable password
The enable password Global Configuration mode command sets a local password to control access
to normal and privilege levels. To remove the password requirement, use the
no form of this
command.
Syntax
enable password [ level level ] password [ encrypted ]
no enable password [ level level ]
•
password —Password for this level, from 1 to 159 characters in length.
•
level level —Level for which the password applies. If not specified the level is 15
(Range: 1-15).
•
encrypted —Encrypted password entered, copied from another device configuration.
Default Configuration
This command has no default configuration.
Command Mode
Global Configuration mode
User Guidelines
• There are no user guidelines for this command.
Console (config-line)# password secret

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
