Dell PowerConnect 5324 Command Line Interface Reference Manual

202 Port Channel Commands
www.dell.com | support.dell.com
Default Configuration
This command has no default configuration.
Command Mode
Global Configuration mode
User Guidelines
• Commands under the interface range context are executed independently on each interface
in the range: If the command returns an error on one of the interfaces, it will not stop the
execution of the command on other interfaces.
Example
The following example shows how port-channels 1, 2 and 8 are grouped to receive the same
command.
channel-group
The channel-group Interface Configuration mode command associates a port with a port-channel.
To remove a port from a port channel, use the
no form of this command.
Syntax
channel-group port-channel-number mode { on | auto }
no channel-group
• port-channel_number —Specifies the number of the valid port-channel for the current
port to join.
•
on —Forces the port to join a channel.
•
auto —Allows the port to join a channel as a result of an LACP operation.
Default Configuration
The port is not assigned to any port-channel.
Command Mode
Interface Configuration (Ethernet) mode
User Guidelines
• There are no user guidelines for this command.
Console (config)# interface range port-channel 1-2
Console (config-if)#

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
