Dell PowerConnect 5324 Command Line Interface Reference Manual

RMON Commands 227
rmon collection history
The rmon collection history Interface Configuration mode command enables a Remote
Monitoring (RMON) MIB history statistics group on an interface. To remove a specified RMON
history statistics group, use the
no form of this command.
Syntax
rmon collection history index [ owner ownername ] [ buckets bucket-number ] [ interval seconds ]
no rmon collection history index
• index —The requested statistics index group. (Range: 1 - 65535)
•
owner ownername —Records the RMON statistics group owner name. If unspecified, the
name is an empty string.
•
buckets bucket-number —A value associated with the number of buckets specified for the
RMON collection history group of statistics. If unspecified, defaults to 50.
(Range: 1 - 65535)
•
interval seconds —The number of seconds in each polling cycle. If unspecified, defaults to
1800. (Range: 1 - 3600)
Default Configuration
This command has no default configuration.
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• This command cannot be executed on multiple ports using the interface range ethernet
command.
256 to 511 Octets The total number of packets (including bad packets) received that are
between 256 and 511 octets in length inclusive (excluding framing bits but
including FCS octets).
512 to 1023 Octets The total number of packets (including bad packets) received that are
between 512 and 1023 octets in length inclusive (excluding framing bits but
including FCS octets).
1024 to 1518 Octets The total number of packets (including bad packets) received that are
between 1024 and 1518 octets in length inclusive (excluding framing bits but
including FCS octets).

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
