Dell PowerConnect 5324 Command Line Interface Reference Manual

120 Ethernet Configuration Commands
www.dell.com | support.dell.com
Command Mode
Global Configuration mode
User Guidelines
• Commands under the interface range context are executed independently on each active
interface in the range. If the command returns an error on one of the active interfaces, it does
not stop executing commands on other active interfaces.
Example
The following example shows how ports g18 to g20 and ports g22 to g24 are grouped to receive the
same command.
shutdown
The shutdown Interface Configuration mode command disables interfaces. To restart a disabled
interface, use the
no form of this command.
Syntax
shutdown
no shutdown
Default Configuration
The interface is enabled.
Command Mode
Interface Configuration (Ethernet, port-channel) mode
User Guidelines
• There are no user guidelines for this command.
Examples
The following example disables port g5.
Console(config)# interface range ethernet g18 - g20, g22 - g24
Console(config-if)#
Console(config)# interface ethernet g5
Console(config-if)# shutdown

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
