Spanning-Tree Commands 289
Guard root: Disabled BPDU guard: Disabled
Number of transitions to forwarding state: 1
BPDU: sent 2, received 170638
Port 4 (1/4) enabled
State: Forwarding Role: Designated
Port id: 128.4 Port cost: 20000
Type: Shared (configured: auto) Internal Port Fast: No (configured:no)
Designated bridge Priority: 32768 Address: 00:02:4b:29:7a:00
Designated port id: 128.2 Designated cost: 20000
Guard root:Disabled BPDU guard: Disabled
Number of transitions to forwarding state: 1
BPDU: sent 2, received 170638
Console# show spanning-tree
Spanning tree enabled mode MSTP
Default port cost method: long
###### MST 0 Vlans Mapped: 1-9
CST Root ID Priority 32768
Address 00:01:42:97:e0:00
Path Cost 20000
Root Port 1 (1/1)
Hello Time 2 sec Max Age 20 sec Forward
Delay 15 sec
IST Master ID Priority 32768
