Dell PowerConnect 5324 Command Line Interface Reference Manual

22 Command Groups
www.dell.com | support.dell.com
PHY Diagnostics Diagnoses and displays the interface status.
Port Channel Configures and displays Port channel information.
Port Monitor Monitors activity on specific target ports.
QoS Configures and displays QoS information.
RADIUS Configures and displays RADIUS information.
RMON Displays RMON statistics.
SNMP Configures SNMP communities, traps and displays SNMP
information.
Spanning Tree
Configures and reports on Spanning Tree protocol
SSH Configures SSH authentication.
Syslog Commands Manages and displays syslog messages.
System Management Configures the device clock, name and authorized users.
TACACS
Configures TACACS commands
User Interface Describes user commands used for entering CLI commands.
VLAN Configures VLANs and displays VLAN information.
Web Server Configures Web based access to the device.
802.1x
Configures commands related to 802.1x security protocol.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
