Dell PowerConnect 5324 Command Line Interface Reference Manual

230 RMON Commands
www.dell.com | support.dell.com
Examples
The following example displays RMON Ethernet Statistics history for "throughput" on index
number 5.
The following example displays RMON Ethernet Statistics history for "errors" on index number 5.
The following example displays RMON Ethernet Statistics history for "other" on index number 5.
Console# show rmon history 5 throughput
Sample Set: 1 Owner: CLI
Interface: g1 Interval: 1800
Requested samples: 50 Granted samples: 50
Maximum table size: 500
Time Octets Packets Broadcast Multicast %
------------------ --------- ------- ---------- --------- -----
Jan 18 2002 21:57:00 303595962 357568 3289 7287 19.98%
Jan 18 2002 21:57:30 287696304 275686 2789 2789 20.17%
Console# show rmon history 5 errors
Sample Set: 1 Owner: CLI
Interface: g1 Interval: 1800
Requested samples: 50 Granted samples: 50
Maximum table size: 500
Time CRC Align Undersize Oversize Fragments Jabbers
------------------ --------- --------- -------- --------- -------
Jan 18 2002 21:57:00 1 1 49 0 0
Jan 18 2002 21:57:30 1 1 27 0 0

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
