Dell PowerConnect 5324

286 Spanning-Tree Commands
www.dell.com | support.dell.com
Designated port id: 128.25 Designated path cost: 0
Guard root:Disabled BPDU guard: Disabled
Number of transitions to forwarding
state: 1
BPDU: sent 2, received 120638
Console# show spanning-tree mst-configuration
Name: Region1
Revision: 1
Instance Vlans Mapped State
0 1-9,21-4094 Enabled
1 10-20 Enabled
Console# show spanning-tree
Spanning tree enabled mode MSTP
Default port cost method: long
###### MST 0 Vlans Mapped: 1-9
CST Root ID Priority 32768
Address 00:01:42:97:e0:00
Path Cost 20000
Root Port 1 (1/1)
Hello Time 2 sec Max Age 20 sec Forward
Delay 15 sec
IST Master ID Priority 32768
Address 00:02:4b:29:7a:00
