Dell PowerConnect 5324 Command Line Interface Reference Manual

46 Command Modes
www.dell.com | support.dell.com
interface range ethernet Enters the interface configuration mode to configure multiple ethernet
type interfaces.
interface range port-channel Enters the interface configuration mode to configure multiple port-
channels.
interface range vlan Enters the interface configuration mode to configure multiple VLANs.
interface vlan Enters the interface configuration (VLAN) mode.
ip default-gateway Defines a default gateway.
ip domain-lookup Enables the IP Domain Naming System (DNS)-based host name-to-
address translation.
ip domain-name Defines a default domain name, that the software uses to complete
unqualified host names.
ip host Defines static host name-to-address mapping in the host cache.
ip http authentication Specifies authentication methods for http.
ip http port Specifies the TCP port for use by a web browser to configure the
device.
ip http server
Enables the device to be configured from a browser .
ip https authentication Specifies authentication methods for https
ip https certificate Configures the active certificate for HTTPS. Use the
no form of this
command to return to default.
ip https server Enables the device to be configured from a secured browser .
ip https port Configures a TCP port for use by a secure web browser to configure
the device.
ip igmp snooping (Global) Enables Internet Group Management Protocol (IGMP) snooping
ip name-server Sets the available name servers.
ip ssh port Specifies the port to be used by the SSH server.
ip ssh pubkey-auth Enables public key authentication for incoming SSH sessions.
ip ssh server Enables the device to be configured from a SSH server.
lacp system-priority Configures the system LACP priority.
line Identifies a specific line for configuration and enters the line
configuration command mode.
logging Logs messages to a syslog server.
logging buffered Limits syslog messages displayed from an internal buffer based on
severity.
logging buffered size Changes the number of syslog messages stored in the internal buffer.
logging console Limits messages logged to the console based on severity.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
