Dynon Avionics SkyView Classic - Page 158

SV-EMS-220/221 Installation and Configuration
7-18 SkyView System Installation Guide - Revision AA
Pin
Rotax 912
Harness
(except 912 iS)
(100399-004)
4-cyl Harness
(100399-001)
6-cyl Harness
(100399-002)
Wire
Color
Function
Sensor Config
1
Do not connect
2

Red
CHT 6
J thermocouple
3

Red
EGT 6
K thermocouple
4

Red
CHT 5
J thermocouple
5

Red
EGT 5
K thermocouple
6


Red
CHT 4
J thermocouple
7


Red
EGT 4
K thermocouple
8


Red
CHT 3
J thermocouple
9


Red
EGT 3
K thermocouple
10


Red
CHT 2
J thermocouple
11



Red
EGT 2
K thermocouple
12


Red
CHT 1
J thermocouple
13



Red
EGT 1
K thermocouple
14

White
CHT 6
J thermocouple
15

Yellow
EGT 6
K thermocouple
16

White
CHT 5
J thermocouple
17

Yellow
EGT 5
K thermocouple
18


White
CHT 4
J thermocouple
19


Yellow
EGT 4
K thermocouple
20


White
CHT 3
J thermocouple
21


Yellow
EGT 3
K thermocouple
22


White
CHT 2
J thermocouple
23



Yellow
EGT 2
K thermocouple
24


White
CHT 1
J thermocouple
25



Yellow
EGT 1
K thermocouple
Table 31 – SV-EMS-220/221 D25F Pin-to-Sensor Compatibility
The Rotax harness only has EGTs 1 and 2 wired, as the EMS measures the Rotax-supplied
resistive CHTs through its GP inputs. The four-cylinder harness only has EGTs 1 through 4 and
CHTs 1 through 4 wired. On the supplied harness, each pair of wires is encased in brown
insulation and labeled with corresponding cylinder number. Inside the outer insulations, each
wire in the pair has the color listed in Table 31 and Figure 60.
If you make a custom thermocouple harness, note that all differential
thermocouple inputs on the D25 and the D37 (SV-EMS-220 only) connectors are
compatible with both J and K type thermocouples. Note that you will need to
