Configuring the ECN330-switch
3071553-KDU 137 365 Uen D 2006-06-16
CLI – This example configures VLAN 5 as a primary VLAN, and VLAN 6 as a
community VLAN and VLAN 7 as an isolated VLAN.
6.12.2.3 Associating VLANs
Each isolated VLAN must be associated with a primary VLAN.
Command Attributes
• Primary VLAN ID – ID of primary VLAN (1-4094).
• Association – Isolated VLANs associated with the selected primary
VLAN.
• Non-Association – Isolated VLANs not associated with the selected
primary VLAN.
Web – Click VLAN, Private VLAN, Association. Select the required primary
VLAN from the scroll-down box, highlight one or more isolated VLANs in the
Non-Association list box, and click Add to associate these entries with the
selected primary VLAN. (An isolated VLAN can only be associated with one
primary VLAN.)
Figure 122 Private VLAN Association
Console(config)#vlan database
Console(config-vlan)#private-vlan 3 primary
Console(config-vlan)#private-vlan 4 isolated
Console(config-vlan)#private-vlan 5 isolated
Console(config-vlan)#
