Configuring the ECN330-switch
3091553-KDU 137 365 Uen D 2006-06-16
Web – Click VLAN, Private VLAN, Port Information or Trunk Information.
Figure 123 Private VLAN Port Information
CLI – This example shows the ECN330-switch configured with primary VLAN 3
and isolated VLANs 4 and 5. Port 3 has been configured as a promiscuous port
and mapped to VLAN 3, while ports 4 and 5 have been configured as isolated
ports and associated with VLAN 4 and 5 respectively. This means that traffic for
port 4 and 5 can only pass through port 3.
6.12.2.5 Configuring Private VLAN Interfaces
Use the Private VLAN Port Configuration and Private VLAN Trunk Configuration
menus to set the private VLAN interface type, and assign the interfaces to a
private VLAN.
Command Attributes
• Port/Trunk – The ECN330 interface.
• PVLAN Port Type – Sets the private VLAN port types.
• Normal – The port is not configured in a private VLAN.
Console#show vlan private-vlan
Primary Secondary Type Interfaces
-------- ----------- ---------- ---------------------------------
3 Primary Eth1/ 3
3 4 Isolated Eth1/ 4
3 5 Isolated Eth1/ 5
Console#
