Configuring the ECN330-switch
332 1553-KDU 137 365 Uen D 2006-06-16
CLI – The following example shows how to assign WRR weights to each of the
priority queues.
6.14.1.5 Setting the Minimum Bandwidth for WFQ
Use the WFQ Minimum Bandwidth Configuration page to assign a minimum
bandwidth to each of the priority queues when using Weighted Fair Queueing
(WFQ).
Command Usage
• WFQ shares bandwidth at the egress ports by specifying a minimum
bandwidth for each queue. Guaranteed bandwidth is first supplied to
each queue, any remaining bandwidth is distributed in a round-robin
fashion.
• Use the Queue Mode page (see “Selecting the Queue Mode” on
page 329) to set the queue mode to WFQ or Strict-WFQ before setting
the minimum queue bandwidths.
Console(config)#queue bandwidth 1 3 5 7 9 11 13 15
Console(config)#exit
Console#show queue bandwidth
Information of Eth 1/1
Queue ID Weight
-------- ------
0 1
1 2
2 4
3 6
4 8
5 10
6 12
7 14
Information of Eth 1/2
Queue ID Weight
.
.
.
