Configuring the ECN330-switch
394 1553-KDU 137 365 Uen D 2006-06-16
CLI
– This example creates VRRP group 1, sets the ECN330-switch as the
master virtual router by assigning the interface address for the selected VLAN to
the virtual IP address. It then sets all of the other VRRP parameters, and then
displays the configured settings.
6.19.1.2 Displaying VRRP Global Statistics
The VRRP Global Statistics page displays counters for errors found in VRRP
protocol packets.
Field Attributes
• VRRP Packets with Invalid Checksum – The total number of VRRP
packets received with an invalid VRRP checksum value.
• VRRP Packets with Unknown Error – The total number of VRRP
packets received with an unknown or unsupported version number.
• VRRP Packets with Invalid VRID – The total number of VRRP packets
received with an invalid VRID for this virtual router.
Console(config)#interface vlan 1
Console(config-if)#vrrp 1 ip 192.168.1.6
Console(config-if)#vrrp 1 timers advertise 5
Console(config-if)#vrrp 1 preempt delay 10
Console(config-if)#vrrp 1 priority 1
Console(config-if)#vrrp 1 authentication bluebird
Console(config-if)#end
Console#show vrrp
Vlan 1 - Group 1,
state Master
Virtual IP address 192.168.1.6
Virtual MAC address 00-00-5E-00-01-01
Advertisement interval 5 sec
Preemption enabled
Min delay 10 sec
Priority 1
Authentication SimpleText
Authentication key bluebird
Master Router 192.168.1.6
Master priority 255
Master Advertisement interval 5 sec
Master down interval 15
Console#
