Configuring the ECN330-switch
410 1553-KDU 137 365 Uen D 2006-06-16
CLI - This example shows all entries in the ARP cache. it also shows how to
convert a Edenic address to a static address, and then clears the remaining
entries in the ARP cache.
6.20.5.5 Displaying Local ARP Entries
The ARP cache also contains entries for local interfaces, including subnet, host,
and broadcast addresses.
Command Attributes
• IP Address – IP address of a local entry in the cache.
• MAC Address – MAC address mapped to the corresponding IP
address.
• Interface – VLAN interface associated with the address entry.
• Entry Count – The number of local entries in the ARP cache.
Console#show arp
Arp cache timeout: 1200 (seconds)
IP Address MAC Address Type Interface
--------------- ----------------- --------- -----------
10.1.0.11 00-11-22-33-44-55 static 2
10.1.0.22 00-00-12-33-89-76 other 2
192.168.0.1 00-0f-3d-12-40-e1 dynamic 247
192.168.0.146 00-00-12-33-89-76 other 247
192.168.0.196 00-10-b5-51-69-f7 dynamic 247
192.168.1.250 00-00-12-33-89-76 other 248
Total entry : 6
Console#configure
Console(config)#arp 192.168.0.1 00-0f-3d-12-40-e1
Console(config)#end
Console#clear arp-cache
This operation will delete all the dynamic entries in ARP Cache.
Are you sure to continue this operation (y/n)?y
Console#
