Configuring the ECN330-switch
4891553-KDU 137 365 Uen D 2006-06-16
Web – Click Routing Protocol, PIM-DM, Interface Information.
Figure 226 PIM-DM Interface Information
CLI – This example shows the PIM-DM interface summary for VLAN 1.
6.21.4.4 Displaying Neighbor Information
The router can display all the neighboring PIM-DM routers.
Command Attributes
• Neighbor Address – IP address of the next-hop router.
• Interface – VLAN that is attached to this neighbor.
• Up time – The duration this entry has been active.
• Expire – The time before this entry will be removed.
• Mode – PIM mode used on this interface.
Console#show ip pim interface 1
Vlan 1 is up
PIM is enabled, mode is Dense.
Internet address is 10.1.0.253.
Hello time interval is 30 sec, trigger hello time interval is 5
sec.
Hello holdtime is 105 sec.
Join/Prune holdtime is 210 sec.
Graft retry interval is 3 sec, max graft retries is 2.
DR Internet address is 10.1.0.253, neighbor count is 1.
Console#
