Configuring the ECN330-switch
5071553-KDU 137 365 Uen D 2006-06-16
Web – Click Routing Protocol, PIM-SM, RP Hash. Enter a multicast group
address, and click Query.
Figure 234 Displaying the Results of the RP Hash
CLI – This example displays the RP used for the specified group, and the
method in which this RP was elected (that is , bootstrap or static).
6.21.5.8 Displaying the BSR Router
Use the BSR Router Information page to display information about the bootstrap
router (BSR).
Field Attributes
PIMV2 Bootstrap Information
• BSR Status – Shows if this router is the BSR.
• BSR Address – IP address of interface configured as the BSR.
• BSR Priority – Priority assigned to this interface for use in the BSR
election process.
Console#show ip pim rp-hash 224.0.1.3
RP: 10.10.11.35
Info source: 10.10.11.35, via bootstrap
Console#sh ip pim rp-hash 224.0.0.0
RP: 192.168.1.19,Static
Console#
