Initial Configuration
48 1553-KDU 137 365 Uen D 2006-06-16
5.3.5.2 Trap Receivers
SNMP stations that are to receive traps from the ECN330-switch can also be
specified.
To configure a trap receiver, use the snmp-server host command. From the
Privileged Exec level global configuration mode prompt, type:
snmp-server host <host-address> <community-string>
[version {1 | 2c | 3 {auth | noauth | priv}}]
where host-address is the IP address for the trap receiver, community-
string specifies access rights for a version 1/2c host, or is the user name of a
version 3 host, version indicates the SNMP client version, and auth |
noauth | priv means that authentication, no authentication, or
authentication and privacy is used for v3 clients. Then press <Enter>.
For a more detailed description of these parameters, see section 7.6.6 on page
615. The following example creates a trap host for each type of SNMP client
5.3.5.3 Configuring Access for SNMP Version 3 Clients
To configure management access for SNMPv3 clients, first create a view that
defines the portions of MIB that the client can read or write, assign the view to a
group, and then assign the user to a group.
The following example creates one view called “mib-2” that includes the entire
MIB-2 tree branch, and then another view that includes the IEEE 802.1d bridge
MIB. It assigns these respective read and read/write views to a group call “r&d”
and specifies group authentication through MD5 or SHA. In the last step, it
assigns a v3 user to this group, indicating that MD5 will be used for
authentication, provides the password “greenpeace” for authentication, and the
password “einstien” for encryption.
Console(config)#snmp-server host 10.1.19.23 batman
Console(config)#snmp-server host 10.1.19.98 robin version 2c
Console(config)#snmp-server host 10.1.19.34 barbie version 3 auth
Console(config)#
