Command Line Interface
8091553-KDU 137 365 Uen D 2006-06-16
Command Usage
The MST region name (section 7.15.12 on page 807) and revision number
are used to designate a unique MST region. A bridge (that is, spanning-tree
compliant device such as the ECN330-switch) can only belong to one MST
region. And all bridges in the same region must be configured with the same
MST instances.
Example
Related Commands
name (section 7.15.12 on page 807)
7.15.14 max-hops
This command configures the maximum number of hops in the region before a
BPDU is discarded. Use the no form to restore the default.
Syntax
max-hops <hop-number>
hop-number - Maximum hop number for multiple spanning tree.
(Range: 1-40)
Default Setting
20
Command Mode
MST Configuration
Console(config-mstp)#revision 1
Console(config-mstp)#
