Configuring the ECN330-switch
82 1553-KDU 137 365 Uen D 2006-06-16
• IP Address – Address of the VLAN to which the management station is
attached. Valid IP addresses consist of four numbers, 0 to 255,
separated by periods. (Default: 0.0.0.0)
• Subnet Mask – This mask identifies the host address bits used for
routing to specific subnets. (Default: 255.0.0.0)
• Default Gateway – IP address of the gateway router between this
device and management stations that exist on other network segments.
(Default: 0.0.0.0)
6.3.8.1 Manual Configuration
Web – Click IP, General, Routing Interface. Select the VLAN through which the
management station is attached, set the IP Address Mode to “Static,” and
specify a “Primary” interface. Enter the IP address, subnet mask and gateway,
then click Apply.
Figure 16 IP Interface Configuration - Manual
