Command Line Interface
902 1553-KDU 137 365 Uen D 2006-06-16
7.19.3 queue bandwidth
This command assigns weighted round-robin (WRR) weights to the eight class
of service (CoS) priority queues. Use the no form to restore the default weights.
Syntax
queue bandwidth <weight0...weight7>
no queue bandwidth
weight0...weight7 - The ratio of weights for queues 0 - 7
determines the weights used by the WRR scheduler. (Range: 1 - 15)
Default Setting
Weights 1, 2, 4, 6, 8, 10, 12, 14 are assigned to queues 0 - 7 respectively.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
WRR controls bandwidth sharing at the egress port by defining scheduling
weights.
Example
The following example shows how to assign WRR weights of 1, 3, 5 and 7 to the
CoS priority queues 0, 1, 2 and 3:
Related Commands
show queue bandwidth (section 7.19.7 on page 906)
Console#configure
Console(config)#int eth 1/5
Console(config-if)#queue bandwidth 1 3 5 7 9 11 13 15
Console(config-if)#
