153
Converter1 Crop
Parameter Default Setting range (Steps) Description
H Left 0 Pixel
Variable
*1
(2 Pixel)
Crops the left side of the video.
H Right 0 Pixel
Variable
*1
(2 Pixel)
Crops the right side of the video.
V Top 0 Line
Variable
*1
(1 Line)
Crops the top of the video.
V Bottom 0 Line
Variable
*1
(1 Line)
Crops the bottom of the video.
The Converter1 Crop setting cannot be changed if Converter1 Process Mode is set to
BY-PASS. Also, it cannot be changed if the conversion is set to the formats indicated as
(BY-PASS) in the CONV1 Conversion Table (5-3-2).
*1 The Converter1 Crop setting range varies depending on the Sync Format settings in FS
Mode (9-4-1 Video System).
IMPORTANT
The cropping setting range resets itself if the video input changes. If the set value
exceeds the setting range due to an input change, the set value will automatically
reset itself to the default value. If the set value exceeds the horizontal range, the H Left
and H Right settings will reset to their default values. If the value exceeds the vertical
range, the V Top and V Bottom settings will also reset accordingly.
Converter1 Side Cut Color
Parameter Default Setting range Description
Red, Green, Blue 0 0 - 255
Sets background color that will be visible if the
converted image is set smaller than the original
under Converter1 Size (5-3-3).
R, G, and B components can be adjusted
separately.
Control knob F4 allows you to adjust R, G, and
B at the same time.
The Converter1 Side Cut Color setting cannot be changed if Converter1 Process Mode is set
to BY-PASS. Also, it cannot be changed if the conversion is set to the formats indicated as
(BY-PASS) in the CONV1 Conversion Table (5-3-2).
