FOR-A FA-9500 - 9-4-3. ANC Settings

186
After completing the settings, click Close to close the dialog box.
Click Refresh to update the settings.
 Dolby Decoder Input Select
Parameter Default Setting range Description
Dolby Input AUX Input
AUX Input
Source 1/2 -15/16
Selects source audio signals to
input to the Dolby decoder.
AUX Input: Input signal in optional
Dolby input connector (Dolby IN).
Source 1/2 – 15/16: SOURCE
signals selected in the9-3-4
“Source Select” menu.
Bit Stream -
Dolby Digital 32bit
Dolby Digital 16bit 1CH
Dolby Digital 16bit 2CH
Dolby Digital 16bit 1/2CH
Dolby E 24bit
Dolby E 20bit
Dolby E 16bit
PCM
Loss
Error
Displays signal type and bit width
of signal selected under INPUT.
PCM: Normal audio signal
Loss: No signal
Error: Unidentifiable
Program
Config
-
Dolby E 5.1+2
Dolby E 5.1+2x1
Dolby E 4+4
Dolby E 4+2x2
Dolby E 4+2+2x1
Dolby E 4+4x1
Dolby E 4x2
Dolby E 3x2+2x1
Dolby E 2x2+4x1
Dolby E 2+6x1
Dolby E 8x1
Dolby E 5.1
Dolby E 4+2
Dolby E 4+2x1
Dolby E 3x2
Dolby E 2x2+2x1
Dolby E 2+4x1
Dolby E 6x1
Dolby E 4
Dolby E 2+2
Dolby E 2+2x1
Dolby E 4x1
Dolby E 7.1
Dolby E 7.1Screen
NON-Dolby E
Displays Dolby E program
configuration (Coding mode) or
status of signal selected under
INPUT.
See Dolby E/Digital Decoder
Output Channel Assignment table
in section 13 “Dolby E
Decoder/Encoder Channel
Assignment Table” for channel
assignments of respective
configurations.
Dolby Digital 1+1
Dolby Digital 1/0
Dolby Digital 2/0
Dolby Digital 3/0
Dolby Digital 2/1
Dolby Digital 3/1
Dolby Digital 2/2
Dolby Digital 3/2
Dolby Digital 3/0L
Dolby Digital 2/1L
Dolby Digital 3/1L
Dolby Digital 2/2L
Dolby Digital 3/2L
Loss
Invalid
