Video Position
Parameter Default Setting range (Steps) Description
H Position
0 Pixel
525/60i ±92
625/50 ±92
1080/59i ±240
1080/50i ±240
1080/23PsF ±240
1080/24PsF ±240
720/59p ±160
720/50p ±160
1080/59p ±240
1080/50p ±240 (Pixel)
Adjusts the horizontal/vertical
position of output videos.
V Position
0 Line
525/60i ±30
625/60i ±36
1080/59i ±68
1080/50i ±68
1080/23PsF ±68
1080/24PsF ±68
720/59p ±90
720/50p ±90
1080/59p ±135
1080/50p ±135 (Line)
Freeze Settings
Parameter Default Setting range Description
Freeze On/Off
*1
Off Off, On Sets FREEZE ON/OFF
Freeze Mode
*2
Frame
Frame,
Odd, Even
Select an operation mode for FREEZE.
Strobe Freeze 0 0 – 255
Sets the interval to refresh the images by the
number of fields for the field or frame freeze.
(“0” will not refresh the image.)
*1 Changing the FS Mode or Synchro Mode setting while Freeze On/Off is set to On will turn
freeze Off. Freeze On/Off cannot be set to On if Synchro mode is set to Line Sync, AVDL,
or Input Lock. Freeze is always set to Off at startup. These settings are not stored in the
event memory.
*2 Freeeze Mode is automatically set to Frame for progressive and progressive segmented
frame input signals and cannot be changed. See the below Freeze Mode Setting Chart for
details.
Freeze Mode Setting Chart
Input signal
Sync
Format
settings
525/60 625/50 1080/59i 1080/50i 720/59p 720/50p 1080/23PsF 1080/24PsF 1080/59p 1080/50p
AUTO OE OE OE OE F F F F F F
525/60 OE NOE NOE NOE NOE NOE NOE NOE NOE NOE
625/50 NOE OE NOE NOE NOE NOE NOE NOE NOE NOE
1080/59i NOE NOE OE NOE NOE NOE NOE NOE NOE NOE
1080/50i NOE NOE NOE OE NOE NOE NOE NOE NOE NOE
720/59p NF NF NF NF F NF NF NF NF NF
720/50p NF NF NF NF NF F NF NF NF NF
1080/23PsF NF NF NF NF NF NF F NF NF NF
1080/24PsF NF NF NF NF NF NF NF F NF NF
1080/59p NF NF NF NF NF NF NF NF F NF
1080/50p NF NF NF NF NF NF NF NF NF F
OE: Can be set to Frame, Odd, or Even.
F: Fixed to Frame.
NOE: Can be set to Frame, Odd, or Even, but the image does not appear properly.
NF: Fixed to Frame, and the image does not appear properly.
