216
 Video Input Status
Item Display Description
SDI1 In
Loss
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p
1080/50p
BY-PASS
Unknown
Displays the video format of the SDI1 input signal.
Displays “Loss” if there is no input signal.
Displays “Unknown” if there is an unsupported input signal.
Displays “BY-PASS” if the function is enabled.
SDI2 In
Loss
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p *1
1080/50p *1
BY-PASS
Unknown
-----
Displays the video format of the SDI2 input signal.
Displays “Loss” if there is no input signal.
Displays “Unknown” if there is an unsupported input signal.
Displays “BY-PASS” if the function is enabled.
Displays “-----“ indicating no SDI2 input detection if 9-2-1
Input Select is set to YPbPr SMPTE, YPbPr BETACAM,
RGB, or Y/C.
Composite In
Loss
525/60
625/50
BY-PASS
Unknown
Displays the video format of the COMPOSITE input signal.
Displays “Loss” if there is no input signal.
Displays “Unknown” if there is an unsupported input signal.
Displays “BY-PASS” if the function is enabled.
Reference
Loss
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
PAL-M
*1
Unknown
Displays the video format of the genlock input signal.
Displays “Loss” if there is no input signal.
Displays “Unknown” if there is an unsupported input signal.
Component In
*2
Loss
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
BY-PASS
Unknown
Displays the video format of the Component input signal.
Displays “Loss” if there is no input signal.
Displays “Unknown” if there is an unsupported input signal.
Displays “BY-PASS” if the function is enabled.
*1 Shown when PAL-M Mode Set in the 9-4-1 Video System is set to Enable, or an input signal in
GENLOCK IN connector is 525/60 or PAL-M signal.
*2 Shown if FA-95AIO is installed.
