217
 Video Output Status
Item Display Description
SDI Out 1/2
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p
1080/50p
BY-PASS
Disable
Displays the video format of the SDI1 output signal.
Displays “BY-PASS” if the function is enabled.
Displays “Disable” if there is no signal output.
SDI Out 3/4 Same as above
Displays the video format of the SDI2 output signal.
Displays “BY-PASS” if the function is enabled.
Displays “Disable” if there is no signal output.
Composite Out
525/60
625/50
BY-PASS
Disable
PAL-M
Displays the video format of the COMPOSITE output signal.
Displays “Disable” if there is no signal output.
Displays “PAL-M” if 9-4-1 PAL-M Mode Set is enabled, and
the format setting for the converted output video signal under
Composite Output Setting in the 9-2-11 Output Select menu
is 525/60.
Component
Out
*1
Loss
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
PAL-M
BY-PASS
Disable
Displays the video format of the Component output signal.
Displays “BY-PASS” if the function is enabled.
Displays “Disable” if there is no signal output.
Output signal format will be 525/60, 625/50, or PAL-M if the
Component output is set to Y/C mode.
*1 Shown if the FA-95AIO option is installed.
 Unit Status
Item Display Description
Unit Name FA-9500
Displays the unit name. The default setting is “FA-9500”.
To change the unit name, see Unit Name in section 9-6-1
“Event Control”
FAN1
Normal
Stopped
Displays the status of FAN1.
Normal: Operating normally.
Stopped: FAN1 has stopped.
Turn the unit power off, and contact your dealer if a
replacement is needed.
FAN2
Normal
Stopped
Displays the status of FAN2.
Normal: Operating normally.
Stopped: FAN2 has stopped.
Turn the unit power off, and contact your dealer if a
replacement is needed.
Power1
*1
Normal
Abnormal
Displays the status of DC POWER1.
Normal: The power supply is normal.
Abnormal: DC POWER1 has failed.
A power failure has occurred. Although the unit is working
properly, It is recommended that the power supply unit be
replaced. Contact your dealer if a replacement is necessary.
Power2
*1
Normal
Abnormal
Displays the status of DC POWER2.
Normal: The power supply is normal.
Abnormal: DC POWER2 has failed
A power failure has occurred. Although the unit is working
properly, It is recommended that the power supply unit be
replaced. Contact your dealer if a replacement is necessary.
*1 : Displays “-------” if the optional FA-95PS is not installed.
