SDI1 Input Audio
Item Display Description
CH1 - CH16
Loss
PCM
Silence
Non-PCM
PCM(Async)
Silence (Async)
Non-PCM(Async)
Unknown
Displays the status of audio signal channels CH1 -
CH16 of the SDI1 input signal.
Loss: No audio signals
PCM: Normal audio signal
Silence: Mute signal
Non-PCM: Compressed audio data such as AC3
PCM (Async): Normal audio signal (asynchronous)
Silence (Async) : Mute signal (asynchronous)
Non-PCM (Async) : Compressed audio data such
as AC3 (asynchronous)
Unknown: Unidentifiable
SDI2 Input Audio
Item Display Description
CH1 - CH16
Loss
PCM
Silence
Non-PCM
PCM(Async)
Silence (Async)
Non-PCM(Async)
Unknown
Displays the status of audio signal channels CH1 -
CH16 of the SDI2 input signal.
Loss: No audio signals
PCM: Normal audio signal
Silence: Mute signal
Non-PCM: Compressed audio data such as AC3
PCM (Async): Normal audio signal (asynchronous)
Silence (Async) : Mute signal (asynchronous)
Non-PCM (Async) : Compressed audio data such
as AC3 (asynchronous)
Unknown: Unidentifiable
SDI1/2 Output Audio
Item Display Description
CH1 - CH16
PCM
Silence
Non-PCM
Unknown
Blank
BY-PASS
Displays the status of audio signal channels CH1
through CH16 of the SDI 1/2 output.
PCM: Normal audio signal
Silence: Mute signal
Non-PCM: Compressed audio data such as AC3
Unknown: Unidentifiable
Blank: No audio signal embedding
BY-PASS: By-passed through
SDI3/4 Output Audio
Item Display Description
CH1 - CH16
PCM
Silence
Non-PCM
Unknown
Blank
BY-PASS
Displays the status of audio signal channels CH1
through CH16 of the SDI 3/4 output.
PCM: Normal audio signal
Silence: Mute signal
Non-PCM: Compressed audio data such as AC3
Unknown: Unidentifiable
Blank: No audio signal embedding
BY-PASS: By-passed through
AES Input Audio
Item Display Description
CH1 - CH8
Loss
PCM 48kHz
PCM 44.1kHz
PCM 32kHz
PCM Other
Silence 48kHz
Silence 44.1kHz
Silence 32kHz
Silence Other
Non-PCM
Output Setting
Displays the status of the audio signal input to the
DIGITAL AUDIO IO connectors.
Loss: No audio signals
PCM 48kHz: Normal audio signal (approx. 48kHz)
PCM 44.1kHz: Normal audio signal (approx.
44.1kHz)
PCM 32kHz: Normal audio signal (approx. 32kHz)
PCM Other: Normal audio signal (Other AES)
Silence 48kHz: Mute signal (approx. 48kHz)
Silence 44.1kHz: Mute signal (approx. 44.1kHz)
Silence 32kHz: Mute signal (approx. 32kHz)
Silence Other: Mute signal (Other AES)
Non-PCM: Compressed audio data such as AC3
Output Setting: Connector is set to Output
