FOR-A FA-9500 - Page 236

220
 AES Output Audio
Item Display Description
CH1 - CH8
PCM
Silence
Non-PCM
Unknown
Input Setting
Displays the status of the audio signal output from the
DIGITAL AUDIO IO connectors.
PCM: Normal audio signal
Silence: Mute signal
Non-PCM: Compressed audio data such as AC3
Unknown: Unidentifiable
Input Setting: Connector is set to input
 Dolby AUX Status
Item Display Description
Input
Loss
PCM
NON-PCM
Unknown
Displays status or type of signal input to the optional
Dolby input connector (Dolby IN).
Loss: No audio signal
PCM: Standard audio signal
NON-PCM: Compressed audio data such as Dolby E
encoded data
UNKNOWN: Unknown signal.
Output
PCM
NON-PCM
None
Displays status or type of signal output to the optional
Dolby output connectors (Dolby OUT).
PCM: Standard audio signal
NON-PCM: Compressed audio data such as Dolby E
encoded data
NONE: No signal
Reference
Loss
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
Unknown
Displays signal format of reference signal input to the
optional Dolby REF IN connector.
LOSS: No signal
UNKNOWN: Unknown signal format
 Analog Input Audio
Item Display Description
CH1 - CH4
Loss
In
Displays status of the input audio signal in the
ANALOG AUDIO connector.
Loss: No audio signals
In: Input signal is present
 Analog Output Audio
Item Display Description
CH1 - CH4
Silence
Out
Displays status of the output audio signal from the
ANALOG AUDIO connector.
Silence: Mute signal
Out: Output signal is present
