OID: 1.3.6.1.4.1.20175.1.301.3.3.3. (Remapping analog output)
ANALOG
AUDIO
ANALOG
REMAPPING
Assign Signal CH1
0-15: Source Ch1-16
16: 500Hz
17: 1kHz
18: Silence
19: DOWNMIX-L
20: DOWNMIX-R
21-28: DolbyDecCh1-8
29: DolbyDecDownmix-L
30: Dolb
y
DecDownmi
x
-R
fa95AudioAnalogOutAssignCh1(1) 1 INTEGER ○ ○ - -
A
ssign Signal CH2 同上 fa95AudioAnalogOutAssignCh2(2) 2 INTEGE
R
○ ○ - -
A
ssign Signal CH3 同上 fa95AudioAnalogOutAssignCh3(3) 3 INTEGE
R
○ ○ - -
A
ssign Signal CH4 同上 fa95AudioAnalogOutAssignCh4(4) 4 INTEGE
R
○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.3.4. (
A
udio Mute)
Master Mute Master Mute 0: OFF 1: ON fa95AudioMasterMute 2 INTEGE
R
○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.3.5.1. (Remapping Audio source)
AUDIO
MAPPING
Source/SRC
Set
Audio Source CH1/2
0-7: SDI 1/2-15/16
8-11: AES 1/2-15/16
16-17: Analo
g
1
/
2-3/4
fa95AudioMappingSourcePair1-2 1 INTEGER ○ ○ - -
A
udio Source CH3/4 同上 fa95AudioMappingSourcePair3-4 2 INTEGE
R
○ ○ - -
A
udio Source CH5/6 同上 fa95AudioMappingSourcePair5-6 3 INTEGE
R
○ ○ - -
A
udio Source CH7/8 同上 fa95AudioMappingSourcePair7-8 4 INTEGE
R
○ ○ - -
A
udio Source CH9/10 同上 fa95AudioMappingSourcePair9-10 5 INTEGE
R
○ ○ - -
A
udio Source CH111/12 同上 fa95AudioMappingSourcePair11-12 6 INTEGE
R
○ ○ - -
A
udio Source CH113/14 同上 fa95AudioMappingSourcePair13-14 7 INTEGE
R
○ ○ - -
A
udio Source CH115/16 同上 fa95AudioMappingSourcePair15-16 8 INTEGE
R
○ ○ - -
OID: 1.3.6.1.4.1.20175.1.301.5.2.(Input/Output Video format)
VIDEO IN
VIDEO IN
STATUS
SDI 1 IN
00: Loss
01: 525/60i
02: 625/50i
03: 1080/60i
04: 1080/59i
05: 1080/50i
06: 1080/30PsF
07: 1080/29.97PsF
08: 1080/25PsF
09: 1080/24PsF
10: 1080/23.98PsF
11: 1080/60p
12: 1080/59p
13: 1080/50p
14: 1080/30p
15: 1080/29.97p
16: 1080/25p
17: 1080/24p
18: 1080/23.98p
19: 720/60p
20: 720/59p
21: 720/50p
22: 720/30p
23: 720/29.97p
24: 720/25p
25: 720/24p
26: 720/23.98p
27: 1035/60i
28: 1035/59i
29: Unknown
30: BY-PASS
31: DISABLE
32: none
fa95InSDI1 1 INTEGER - ○ ○ Change
SDI 2 IN 同上 fa95InSDI2 2 INTEGE
R
- ○ ○ Change
Composite IN
0: LOSS1: 525/60
3: 625/50
30:BY-PASS
fa95InComposite 3 INTEGER - ○ ○ Change
Ref Status
00: Loss
01: 525/60i
02: 625/50i
03: 1080/60i
04: 1080/59i
05: 1080/50i
06: 1080/30PsF
07: 1080/29.97PsF
08: 1080/25PsF
09: 1080/24PsF
10: 1080/23.98PsF
11: 1080/60p
12: 1080/59p
13: 1080/50p
14: 1080/30p
15: 1080/29.97p
16: 1080/25p
17: 1080/24p
18: 1080/23.98p
19: 720/60p
20: 720/59p
21: 720/50p
22: 720/30p
23: 720/29.97p
24: 720/25p
25: 720/24p
26: 720/23.98p
27: 1035/60i
28: 1035/59i
29: Unknown
30: BY-PASS
31: Disable
32: none
fa95InReference(11) 11 INTEGER - ○ ○ Change
